XSSMLXL

Specifications

ApplicationsIndoor Limited Use / Limited Access
Capacity1,400 lb
Maximum Travel Distance25 Feet
Cab Dimensions (standard)42"x54"
Cab Dimensions (optional)42"x60", 45"x54", 48"x54", 51"x51"
Speed (per minute)30'
Minimum Overhead Required120"
Drive2:1 Roped Hydraulic
Motor/Pump3-5 HP drive motor with submersible screw pump
TypeLimited-Use / Limited-Application
Cab Heights84"
Max Landings5
Overhead Clearance Required132" without Low Overhead Restrictor
Power Requirement220VAC 1-Phase, 208VAC 3-Phase
Pit Depth14" minimum
EmergencyBattery Emergency Lowering
SafetyFire rated laminate cab walls,

Specifications

ApplicationsIndoor Limited Use / Limited Access
Capacity1,400 lb
Maximum Travel Distance25 Feet
Cab Dimensions (standard)42"x54"
Cab Dimensions (optional)42"x60", 45"x54", 48"x54", 51"x51"
Speed (per minute)30'
Minimum Overhead Required120"
Drive2:1 Roped Hydraulic
Motor/Pump3-5 HP drive motor with submersible screw pump
TypeLimited-Use / Limited-Application
Cab Heights84"
Max Landings5
Overhead Clearance Required132" without Low Overhead Restrictor
Power Requirement220VAC 1-Phase, 208VAC 3-Phase
Pit Depth14" minimum
EmergencyBattery Emergency Lowering
SafetyFire rated laminate cab walls,
